Card style series-Shenzhen Donglaier Intelligent Technology Co., Ltd

IO Coupler Module

Bus protocol Name Model Specs Distance Rate Quarantine
PROFINET Card type IO coupler module PNK00-04P 16DI 16DO (Input bidirectional, output PNP) 100m (station distance) 100Mb/s Optocoupler isolation
PROFINET Card type IO coupler module PNK00-04 16DI 16DO (Input bidirectional, output NPN) 100m (station distance) 100Mb/s Optocoupler isolation
PROFINET Card type IO coupler module PNK00-03P 32DO (output PNP) 100m (station distance) 100Mb/s Optocoupler isolation
PROFINET Card type IO coupler module PNK00-03 32DO (output NPN) 100m (station distance) 100Mb/s Optocoupler isolation
PROFINET Card type IO coupler module PNK00-02 32DI (input bidirectional) 100m (station distance) 100Mb/s Optocoupler isolation
PROFINET Card type IO coupler module PNK00-01P 16DO (output PNP) 100m (station distance) 100Mb/s Optocoupler isolation
PROFINET Card type IO coupler module PNK00-01 16DO (output NPN) 100m (station distance) 100Mb/s Optocoupler isolation
PROFINET Card type IO coupler module PNK00-00 16DI (Input bidirectional) 100m (station distance) 100Mb/s Optocoupler isolation
Modbus /TCP Card type IO coupler module MDTK00-04P 16DI 16DO (Input bidirectional, output PNP) 100m (station distance) 10Mb/s Optocoupler isolation
Modbus /TCP Card type IO coupler module MDTK00-04 16DI 16DO (Input bidirectional, output NPN) 100m (station distance) 10Mb/s Optocoupler isolation
Modbus /TCP Card type IO coupler module MDTK00-03P 32DO (output PNP) 100m (station distance) 10Mb/s Optocoupler isolation
Modbus /TCP Card type IO coupler module MDTK00-03 32DO (output NPN) 100m (station distance) 10Mb/s Optocoupler isolation
Modbus /TCP Card type IO coupler module MDTK00-02 32DI (input bidirectional) 100m (station distance) 10Mb/s Optocoupler isolation
MECHATROLINK Card type IO coupler module M3K00-04P 32DO (output PNP) 100m (station distance) 100Mb/s Optocoupler isolation
MECHATROLINK Card type IO coupler module M3K00-04 16DI 16DO (Input bidirectional, output NPN) 100m (station distance) 100Mb/s Optocoupler isolation
MECHATROLINK Card type IO coupler module M3K00-03P 32DO (output PNP) 100m (station distance) 100Mb/s Optocoupler isolation
MECHATROLINK Card type IO coupler module M3K00-03 32DO (output NPN) 100m (station distance) 100Mb/s Optocoupler isolation
MECHATROLINK Card type IO coupler module M3K00-02 32DI (input bidirectional) 100m (station distance) 100Mb/s Optocoupler isolation
MECHATROLINK Card type IO coupler module M3K00-01P 16DO (output PNP) 100m (station distance) 100Mb/s Optocoupler isolation
MECHATROLINK Card type IO coupler module M3K00-01 16DO (output NPN) 100m (station distance) 100Mb/s Optocoupler isolation
MECHATROLINK Card type IO coupler module M3K00-00 16DI (Input bidirectional) 100m (station distance) 100Mb/s Optocoupler isolation
EtherNet/IP Card type IO coupler module EIK00-04P 16DI 16DO (Input bidirectional, output PNP) 100m (station distance) 100Mb/s Optocoupler isolation
EtherNet/IP Card type IO coupler module EIK00-04 16DI 16DO (Input bidirectional, output NPN) 100m (station distance) 100Mb/s Optocoupler isolation
EtherNet/IP Card type IO coupler module EIK00-03P 32DO (output PNP) 100m (station distance) 100Mb/s Optocoupler isolation
EtherNet/IP Card type IO coupler module EIK00-03 32DO (output NPN) 100m (station distance) 100Mb/s Optocoupler isolation
EtherNet/IP Card type IO coupler module EIK00-02 32DI (input bidirectional) 100m (station distance) 100Mb/s Optocoupler isolation
EtherNet/IP Card type IO coupler module EIK00-01P 16DO (output PNP) 100m (station distance) 100Mb/s Optocoupler isolation
EtherNet/IP Card type IO coupler module EIK00-01 16DO (output NPN) 100m (station distance) 100Mb/s Optocoupler isolation
EtherNet/IP Card type IO coupler module EIK00-00 16DI (Input bidirectional) 100m (station distance) 100Mb/s Optocoupler isolation
EtherCAT Card type IO coupler module ECK00-06P 8DI 8DO (input bidirectional, output PNP) 100m (station distance) 100Mb/s Optocoupler isolation
EtherCAT Card type IO coupler module ECK00-06 8DI 8DO (input bidirectional, output NPN) 100m (station distance) 100Mb/s Optocoupler isolation
EtherCAT Card type IO coupler module ECK00-04P 16DI 16DO (Input bidirectional, output PNP) 100m (station distance) 100Mb/s Optocoupler isolation
EtherCAT Card type IO coupler module ECK00-04 16DI 16DO (Input bidirectional, output NPN) 100m (station distance) 100Mb/s Optocoupler isolation
EtherCAT Card type IO coupler module ECK00-03P 32DO (output PNP) 100m (station distance) 100Mb/s Optocoupler isolation
EtherCAT Card type IO coupler module ECK00-03 32DO (output NPN) 100m (station distance) 100Mb/s Optocoupler isolation
EtherCAT Card type IO coupler module ECK00-02 32DI (input bidirectional) 100m (station distance) 100Mb/s Optocoupler isolation
EtherCAT Card type IO coupler module ECK00-01P 16DO (output PNP) 100m (station distance) 100Mb/s Optocoupler isolation
EtherCAT Card type IO coupler module ECK00-01 16DO (output NPN) 100m (station distance) 100Mb/s Optocoupler isolation
EtherCAT Card type IO coupler module ECK00-00 16DI (Input bidirectional) 100m (station distance) 100Mb/s Optocoupler isolation
CC-Link IE Card type IO coupler module CIK00-04P 16DI 16DO (Input bidirectional, output PNP) 100m (station distance) 100Mb/s Optocoupler isolation
CC-Link IE Card type IO coupler module CIK00-04 16DI 16DO (Input bidirectional, output NPN) 100m (station distance) 100Mb/s Optocoupler isolation
CC-Link IE Card type IO coupler module CIK00-03P 32DO (output PNP) 100m (station distance) 100Mb/s Optocoupler isolation
CC-Link IE Card type IO coupler module CIK00-03 32DO (output NPN) 100m (station distance) 100Mb/s Optocoupler isolation
CC-Link IE Card type IO coupler module CIK00-02 32DI (input bidirectional) 100m (station distance) 100Mb/s Optocoupler isolation
CC-Link IE Card type IO coupler module CIK00-01P 16DO (output PNP) 100m (station distance) 100Mb/s Optocoupler isolation
CC-Link IE Card type IO coupler module CIK00-01 16DO (output NPN) 100m (station distance) 100Mb/s Optocoupler isolation
CC-Link IE Card type IO coupler module CIK00-00 16DI (Input bidirectional) 100m (station distance) 100Mb/s Optocoupler isolation

Hybrid IO module

Bus protocol Name Model Specs Distance Rate Quarantine
EtherCAT Card type 32 point hybrid IO module ECK00-1616P 16DI 16DO (Input bidirectional, output PNP) Optocoupler isolation
EtherCAT Card type 32 point hybrid IO module ECK00-1616 16DI 16DO (Input bidirectional, output NPN) Optocoupler isolation
EtherCAT Card type 16 point hybrid IO module ECK00-0808 8DI 8DO (input PNP, output NPN) Optocoupler isolation

Analog module

Bus protocol Name Model Specs Distance Rate Quarantine
Modbus /TCP Vertical 32-point remote IO module MDTL-DX32 16DI 16DO (Input bidirectional, output NPN) 100m (station distance) 100Mb/s YES
PROFINET Card style 4-way analog module PNAK00-0004 4-way output
PROFINET Card style 4-way analog module PNAK00-0400 4-way input
MECHATROLINK Card style 4-way analog module M3AK00-0004-N 4-way output
MECHATROLINK Card style 4-way analog module M3AK00-0400-N 4-way input
EtherNet/IP Card style 4-way analog module EIAK00-0004 4-way output
EtherNet/IP Card style 4-way analog module EIAK00-0400 4-way input
EtherCAT Card style 8-way analog module ECAK00-0008 8-way output
EtherCAT Card style 8-way analog module ECAK00-0800 8-way input
EtherCAT Card style 4-way analog module ECAK00-0004 4-way output
EtherCAT Card style 4-way analog module ECAK00-0400 4-way input
CC-Link IE Card style 4-way analog module CIAK00-0004-N 4-way output
CC-Link IE Card style 4-way analog module CIAK00-0400-N 4-way input

Analog coupler

Bus protocol Name Model Specs Distance Rate Quarantine
EtherCAT Card type analog coupler ECAK00-01 4-way output 100m (station distance) 100Mb/s Optocoupler isolation
EtherCAT Card type analog coupler ECAK00-00 4-way input 100m (station distance) 100Mb/s Optocoupler isolation

Analog temperature coupler

Bus protocol Name Model Specs Distance Rate Quarantine
EtherCAT Card type analog temperature coupler ECTK00-01 8-way PT100 thermistor input 100m (station distance) 100Mb/s Optocoupler isolation
EtherCAT Card type analog temperature coupler ECTK00-00 8-way input (thermocouple type can be switched) 100m (station distance) 100Mb/s Optocoupler isolation

Temperature acquisition module

Bus protocol Name Model Specs Distance Rate Quarantine
PROFINET 4-way temperature acquisition module PNTK00-0400-PT100 PT100 thermistor temperature input
PROFINET 8-way temperature acquisition module PNTK00-0800-T T-type thermocouple temperature input
PROFINET 8-way temperature acquisition module PNTK00-0800-K K-type thermocouple temperature input
PROFINET 8-way temperature acquisition module PNTK00-0800-J J-type thermocouple temperature input
MECHATROLINK 4-way temperature acquisition module M3TK00-0400-PT100 PT100 thermistor temperature input
MECHATROLINK 8-way temperature acquisition module M3TK00-0800-T T-type thermocouple temperature input
MECHATROLINK 8-way temperature acquisition module M3TK00-0800-K K-type thermocouple temperature input
MECHATROLINK 8-way temperature acquisition module M3TK00-0800-J J-type thermocouple temperature input
EtherNet/IP 8-way temperature acquisition module EITK00-0800-T T-type thermocouple temperature input
EtherNet/IP 8-way temperature acquisition module EITK00-0800-J J-type thermocouple temperature input
EtherNet/IP 8-way temperature acquisition module EITK00-0800-K K-type thermocouple temperature input
EtherNet/IP 4-way temperature acquisition module EITK00-0400-PT100 PT100 thermistor temperature input
EtherCAT 8-way temperature acquisition module ECTK00-0800-T T-type thermocouple temperature input
EtherCAT 8-way temperature acquisition module ECTK00-0800-J J-type thermocouple temperature input
EtherCAT 8-way temperature acquisition module ECTK00-0800-K K-type thermocouple temperature input
EtherCAT 4-way temperature acquisition module ECTK00-0400-PT100 PT100 thermistor temperature input
CC-Link IE 4-way temperature acquisition module CITK00-0400-PT100 PT100 thermistor temperature input
CC-Link IE 8-way temperature acquisition module CITK00-0800-T T-type thermocouple temperature input
CC-Link IE 8-way temperature acquisition module CITK00-0800-J J-type thermocouple temperature input
CC-Link IE 8-way temperature acquisition module CITK00-0800-K K-type thermocouple temperature input

Remote IO module

Bus protocol Name Model Specs Distance Rate Quarantine
PROFINET Card type 32 point remote IO module PNK00-0032P 32DO (output PNP)
PROFINET Card type 32 point remote IO module PNK00-0032 32DO (output NPN)
PROFINET Card type 32 point remote IO module PNK00-3200 32DI (input bidirectional)
PROFINET Card type 16 point remote IO module PNK00-0016P 16DO (output PNP)
PROFINET Card type 16 point remote IO module PNK00-0016 16DO (output NPN)
PROFINET Card type 16 point remote IO module PNK00-1600 16DI (Input bidirectional)
Modbus /TCP Card type 32 point remote IO module MDTK00-0032P 32DO (output PNP)
Modbus /TCP Card type 32 point remote IO module MDTK00-0032 32DO (output NPN)
Modbus /TCP Card type 32 point remote IO module MDTK00-3200 32DI (input bidirectional)
MECHATROLINK Card type 32 point remote IO module M3K00-0032P 32DO (output PNP)
MECHATROLINK Card type 32 point remote IO module M3K00-0032 32DO (output NPN)
MECHATROLINK Card type 32 point remote IO module M3K00-3200 32DI (input bidirectional)
MECHATROLINK Card type 16 point remote IO module M3K00-0016P 16DO (output PNP)
MECHATROLINK Card type 16 point remote IO module M3K00-0016 16DO (output NPN)
MECHATROLINK Card type 16 point remote IO module M3K00-1600 16DI (Input bidirectional)
EtherNet/IP Card type 32 point remote IO module EIK00-0032P 32DO (output PNP)
EtherNet/IP Card type 32 point remote IO module EIK00-0032 32DO (output NPN)
EtherNet/IP Card type 32 point remote IO module EIK00-3200 32DI (input bidirectional)
EtherNet/IP Card type 16 point remote IO module EIK00-0016P 16DO (output PNP)
EtherNet/IP Card type 16 point remote IO module EIK00-0016 16DO (output NPN)
EtherNet/IP Card type 16 point remote IO module EIK00-1600 16DI (Input bidirectional)
EtherCAT Card type 32 point remote IO module ECK00-0032P 32DO (output PNP)
EtherCAT Card type 32 point remote IO module ECK00-0032 32DO (output NPN)
EtherCAT Card type 32 point remote IO module ECK00-3200 32DI (input bidirectional)
EtherCAT Card type 16 point remote IO module ECK00-0016P 16DO (output PNP)
EtherCAT Card type 16 point remote IO module ECK00-0016 16DO (output NPN)
EtherCAT Card type 16 point remote IO module ECK00-1600 16DI (Input bidirectional)
CC-Link IE Card type 32 point remote IO module CIK00-0032P 32DO (output PNP)
CC-Link IE Card type 32 point remote IO module CIK00-0032 32DO (output NPN)
CC-Link IE Card type 32 point remote IO module CIK00-3200 32DI (input bidirectional)
CC-Link IE Card type 16 point remote IO module CIK00-0016P 16DO (output PNP)
CC-Link IE Card type 16 point remote IO module CIK00-0016 16DO (output NPN)
CC-Link IE Card type 16 point remote IO module CIK00-1600 16DI (Input bidirectional)
